Manufactured by PRS Bearings, the PLA32.1100 is a precision PLA32 Series Four-point Contact Ball Slewing Bearings. You may consider it as an interchangeable alternative and replacement for IMO 91-32 0955, Mijnsbergen E.1100.32.00.C, Rothe Erde 281.30.0900. Key dimensional parameters include a mm bore diameter, a mm outer diameter, and a mm overall width. With matching boundary dimensions, this component is designed to meet standard load requirements and ensure consistent operational performance. For comprehensive technical evaluation, please explore the detailed specifications, dimensional data, product images, and CAD drawings provided below. A complete PDF data sheet is also readily available for direct download to support your engineering and procurement needs.
PLA32.1100 - PLA32 Series Four-point Contact Ball Slewing Bearings
Technical Specifications
| Direct Interchange | IMO 91-32 0955, Mijnsbergen E.1100.32.00.C, Rothe Erde 281.30.0900 |
|---|---|
| Overview | |
| Basic Model | PLA32.1100 |
| Weight | 165 kg |
| Mounting Dimensions | |
| Outer Ring O.D. (Da) | 1098 mm |
| Inner Ring I.D. (di) | 805 mm |
| Mounting Holes | |
| Outer Ring Hole Pitch Dia. (La) | 1016 mm |
| Inner Ring Hole Pitch Dia. (Li) | 845 mm |
| No. of Outer Ring Holes (na) | 30 |
| No. of Inner Ring Holes (ni) | 30 |
| Gear Parameters | |
| Pitch Circle Dia. (do) | 1080 mm |
| Module (m) | 9 |
| No. of Teeth (z) | 120 |
PLA32.1100 845 mm 30 mm 805 mm 1016 mm 1098 mm 30 mm Frequently Asked Questions about PLA32.1100 PLA32 Series Four-point Contact Ball Slewing Bearings
Find key technical answers regarding dimensions, specifications, and replacement options for this model.
Certainly. While the standard PLA32.1100 is pre-filled with high-grade industrial lubricant, PRS Bearings can provide custom fills, including food-grade (NSF H1), high-temperature, or extreme-pressure greases tailored to your operational needs.
PRS Bearings recommends storing the PLA32.1100 in its original packaging in a clean, low-vibration warehouse. Maintaining a relative humidity below 60% and a stable room temperature ensures maximum shelf life.
PRS Bearings provides a comprehensive B2B warranty for the PLA32.1100 against manufacturing defects. Furthermore, our engineering team offers ongoing technical support to ensure the PLA32 Series Four-point Contact Ball Slewing Bearings operates optimally within your specific machinery.
Yes. As part of our B2B commitment, if a PLA32.1100 experiences unexpected issues in the field, PRS Bearings engineers can perform detailed metallurgical and wear analysis to identify root causes and optimize your future setups.
