Manufactured by PRS Bearings, the XRSI14.1094 is a precision XRSI Series. You may consider it as an interchangeable alternative and replacement for INA XSI141094N. Key dimensional parameters include a mm bore diameter, a mm outer diameter, and a mm overall width. With matching boundary dimensions, this component is designed to meet standard load requirements and ensure consistent operational performance. For comprehensive technical evaluation, please explore the detailed specifications, dimensional data, product images, and CAD drawings provided below. A complete PDF data sheet is also readily available for direct download to support your engineering and procurement needs.
XRSI14.1094 - XRSI Series
Technical Specifications
| Direct Interchange | INA XSI141094N |
|---|---|
| Overview | |
| Basic Model | XRSI14.1094 |
| Weight | 91 kg |
| Performance | |
| Clearance / Preload | 0.01-0.05 |
| Accuracy | |
| Accuracy A | 0.07 |
| Accuracy B | 0.07 |
| Accuracy C | 0.11 |
| Accuracy D | 0.11 |
| Mounting Dimensions | |
| Outer Ring O.D. (Da) | 1164 mm |
| Inner Ring O.D. (da) | 1091 mm |
| Inner Ring I.D. (di) | 984 mm |
| Outer Ring I.D. (Di) | 1095 mm |
| Mounting Holes | |
| Outer Ring Hole Pitch Dia. (La) | 1140 mm |
| Inner Ring Hole Pitch Dia. (Li) | 1055 mm |
| No. of Outer Ring Holes (na) | 48 |
| No. of Inner Ring Holes (ni) | 48 |
| Gear Parameters | |
| Pitch Circle Dia. (do) | 1000 mm |
| Module (m) | 8 |
| No. of Teeth (z) | 125 |
1164 mm 1140 mm 1095 mm 984 mm 1055 mm 1091 mm XRSI14.1094 48 Frequently Asked Questions about XRSI14.1094 XRSI Series
Find key technical answers regarding dimensions, specifications, and replacement options for this model.
PRS Bearings provides the XRSI14.1094 with various cage options including high-strength pressed steel, machined brass for high-vibration tasks, or reinforced polymers for the quietest operation in precision machinery.
Absolutely. The precise manufacturing of the PRS Bearings XRSI14.1094 results in stable, predictable vibration baselines. This makes it highly compatible with modern IoT condition monitoring sensors for early fault detection.
Every XRSI14.1094 batch undergoes 100% automated vibration and noise testing at the PRS Bearings factory. We guarantee compliance with Z1/V1 standards, with premium Z3/V3 options available for high-end electric motors.
Yes, while the standard PRS Bearings XRSI14.1094 meets ISO P0 (ABEC-1) levels, PRS Bearings also manufactures high-precision variants in P6 (ABEC-3) and P5 (ABEC-5) for applications requiring minimal runout and extreme rotational accuracy.
