Manufactured by PRS Bearings, the PA10013 is a precision Metric Series Bearing. You may consider it as an interchangeable alternative and replacement for KAYDON K10013AR0. Key dimensional parameters include a 100 mm bore diameter, a 126 mm outer diameter, and a mm overall width. With matching boundary dimensions, this component is designed to meet standard load requirements and ensure consistent operational performance. For comprehensive technical evaluation, please explore the detailed specifications, dimensional data, product images, and CAD drawings provided below. A complete PDF data sheet is also readily available for direct download to support your engineering and procurement needs.
PA10013 - Metric Series Bearing
Technical Specifications
| Direct Interchange | KAYDON K10013AR0 |
|---|---|
| Overview | |
| Basic Model | PA10013 |
| Weight | 0.34 kg |
| Dimensions | |
| Bore Dia (d, mm) | 100 mm |
| Outer Dia (D, mm) | 126 mm |
| Load Ratings | |
| Dynamic Load (Cr) | 1013 kN |
| Static Load (Cor) | 1959 kN |
| Dynamic Axial Load (Ca) | 2324 kN |
| Static Axial Load (Coa) | 5656 kN |
126 mm 100 mm PA10013 Frequently Asked Questions about PA10013 Metric Series Bearing
Find key technical answers regarding dimensions, specifications, and replacement options for this model.
The standard PA10013 from PRS Bearings is heat-stabilized for temperatures up to 120°C. For extreme heat applications, PRS Bearings offers custom S1 or S2 stabilization treatments to ensure the component maintains its 100 mm x 126 mm dimensions without warping.
The L10 life of the PRS Bearings PA10013 is calculated based on its 1013 dynamic capacity and your specific application loads. By maintaining clean operating conditions and using PRS Bearings's recommended lubrication, users can expect significantly extended service intervals.
The standard PRS Bearings PA10013 is designed for rigid configurations. For optimal performance, strict alignment of the 100 mm bore is critical, though PRS Bearings engineers can provide self-aligning bearing alternatives if your equipment is prone to deflection.
Every PA10013 batch undergoes 100% automated vibration and noise testing at the PRS Bearings factory. We guarantee compliance with Z1/V1 standards, with premium Z3/V3 options available for high-end electric motors.
