Manufactured by PRS Bearings, the PR045UU is a precision PR Sealed Radial Contact Ball Bearing. You may consider it as an interchangeable alternative and replacement for KAYDON JU045CP0, SILVERTHIN JSU045CP0. Key dimensional parameters include a 114.3 mm bore diameter, a 133.35 mm outer diameter, and a 12.7 mm overall width. With matching boundary dimensions, this component is designed to meet standard load requirements and ensure consistent operational performance. For comprehensive technical evaluation, please explore the detailed specifications, dimensional data, product images, and CAD drawings provided below. A complete PDF data sheet is also readily available for direct download to support your engineering and procurement needs.
PR045UU - PR Sealed Radial Contact Ball Bearing
Technical Specifications
| Direct Interchange | KAYDON JU045CP0, SILVERTHIN JSU045CP0 |
|---|---|
| Overview | |
| Basic Model | PR045UU |
| Weight | 0.277 kg |
| Dimensions | |
| Bore Dia (d, mm) | 114.3 mm |
| Bore Dia (d, in) | 4.5 in |
| Outer Dia (D, mm) | 133.35 mm |
| Outer Dia (D, in) | 5.25 in |
| Width (B, mm) | 12.7 mm |
| Width (B, in) | 0.5 in |
| Load Ratings | |
| Dynamic Load (Cr) | 6,010 kN |
| Static Load (Cor) | 10,410 kN |
| Performance | |
| Limit Speed (rpm) | 1440 rpm |
12.7 mm 114.3 mm 133.35 mm PR045UU Frequently Asked Questions about PR045UU PR Sealed Radial Contact Ball Bearing
Find key technical answers regarding dimensions, specifications, and replacement options for this model.
PRS Bearings recommends storing the PR045UU in its original packaging in a clean, low-vibration warehouse. Maintaining a relative humidity below 60% and a stable room temperature ensures maximum shelf life.
Every PR045UU batch undergoes 100% automated vibration and noise testing at the PRS Bearings factory. We guarantee compliance with Z1/V1 standards, with premium Z3/V3 options available for high-end electric motors.
The PR045UU utilizes high-purity bearing steel treated with PRS Bearings's advanced thermal processes. This creates a tough core that effectively absorbs shock loads while maintaining a highly wear-resistant surface on the raceways.
The PR045UU is engineered with an optimal strength-to-mass ratio. PRS Bearings ensures that the cross-sectional distribution provides maximum structural rigidity for its 6,010 dynamic load rating without introducing excessive rotational inertia.
