Manufactured by PRS Bearings, the PX10020 is a precision X Type Four Point Contact Ball Bearing. You may consider it as an interchangeable alternative and replacement for K10020XP0. Key dimensional parameters include a 100 mm bore diameter, a 140 mm outer diameter, and a mm overall width. With matching boundary dimensions, this component is designed to meet standard load requirements and ensure consistent operational performance. For comprehensive technical evaluation, please explore the detailed specifications, dimensional data, product images, and CAD drawings provided below. A complete PDF data sheet is also readily available for direct download to support your engineering and procurement needs.
PX10020 - X Type Four Point Contact Ball Bearing
Technical Specifications
| Direct Interchange | K10020XP0 |
|---|---|
| Overview | |
| Basic Model | PX10020 |
| Weight | 0.87 kg |
| Dimensions | |
| Bore Dia (d, mm) | 100 mm |
| Outer Dia (D, mm) | 140 mm |
| Load Ratings | |
| Dynamic Load (Cr) | 2,323 kN |
| Static Load (Cor) | 2,618 kN |
| Dynamic Axial Load (Ca) | 3,357 kN |
| Static Axial Load (Coa) | 6,545 kN |
140 mm 140 mm 100 mm 100 mm PX10020 Frequently Asked Questions about PX10020 X Type Four Point Contact Ball Bearing
Find key technical answers regarding dimensions, specifications, and replacement options for this model.
The standard PRS Bearings PX10020 is designed for rigid configurations. For optimal performance, strict alignment of the 100 mm bore is critical, though PRS Bearings engineers can provide self-aligning bearing alternatives if your equipment is prone to deflection.
Certainly. While the standard PX10020 is pre-filled with high-grade industrial lubricant, PRS Bearings can provide custom fills, including food-grade (NSF H1), high-temperature, or extreme-pressure greases tailored to your operational needs.
PRS Bearings recommends storing the PX10020 in its original packaging in a clean, low-vibration warehouse. Maintaining a relative humidity below 60% and a stable room temperature ensures maximum shelf life.
The PX10020 is engineered with an optimal strength-to-mass ratio. PRS Bearings ensures that the cross-sectional distribution provides maximum structural rigidity for its 2,323 dynamic load rating without introducing excessive rotational inertia.
